Elo E321195 1093L 10.1-inch HDMI, VGA, DP, PCAP USB, Clear Elo ET1093L

$445.00
$445.00
-0%
Shipping calculated at checkout.
販売元: Elotouch
Only 10 items in stock! Out of stock!
Enclosure Color: Black
Resolution: 1280 x 800 at 60Hz
Brightness (typical): LCD panel: 500 nits TouchPro PCAP: 450 nits

Guaranteed safe checkout

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • Shop Pay
  • Union Pay
  • Visa

Description

Model 10 Inch Elo 1093L Open Frame Touch Screen Monitor
Part Number(s) TouchPro PCAP (Worldwide) - E321195
Enclosure Color Black
Touch Technology and Capacity PCAP (TouchPro Projected Capacitive) - 10 Touch
Touch Interface USB 2.9
Diagonal Size 10.1'' diagonal, Active matrix TFT LCD (LED)
On Screen Display Accessible through switches on the unit’s tethered OSD Control box.

Controls: Menu, Up, Down, Select, Power

Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Thru

Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese

Lockouts: OSD, Power
Aspect Ratio 16:10
Active Area (mm) 8.54" x 5.34"/ 216.96mm x 135.6mm
Resolution 1280 x 800 at 60Hz
Other Supported Resolutions 640 x 480 60Hz
720 x 400 70Hz
800 x 500 60Hz
800 x 600 56, 60Hz
1024 x 768 60Hz
1280 x 800 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
Viewing Angle Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total
Number of Colors 262,000
Brightness (typical) LCD panel: 350 nits
TouchPro PCAP: 315 nits
Response Time-total (typical) 25 msec
Contrast Ratio 800:1
Video Interface HDMI, VGA & Display Port
Power Supply External DC - Optional power brick (sold separately)
Input Power Connector (Monitor) Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) barrel depth)
Input Voltage 12VDC +/- 5%
Adapter Output Power Connector DC barrel plug (2.1mm (+/- 0.1mm) pin inner diameter, 5.5mm (+/- 0.05mm) barrel outer diameter, 9.5mm (+/- 0.3mm) barrel length)
Power Consumption (Typical) Monitor + Adapter at 230V/50Hz
ON: 6.1 W
SLEEP: 0.7 W
OFF: 0.5W
Dimensions 10.07" x 7.03" x 1.45" / 255.8mm x 178.5mm x 36.9mm
Shipping Box Dimensions 13.23" x 10.31" x 6.89" / 336mm x 262mm x 175mm
Weight (Unpackaged) 2.65 lbs / 1.2 kg
Weight (Packaged) 5.73 lbs / 2.6 kg
Operating Temperature 0°C to 40°C / 32°F to 104°F
Storage Temperature -20°C to 60°C / -4°F to 140°F
Humidity
Operating: 20% to 80% Storage: 10% to 95%
Sealability Touchscreen sealed to bezel; Touchscreen sealed to LCD
MTBF 50,000 hours demonstrated
Warranty 3-year
Extended Warranty Options 4 year warranty coverage - Elo P/N: E898247
5 year warranty coverage - Elo P/N: E898449
3 year warranty coverage + AUR - Elo P/N: E898648
4 year warranty coverage + AUR - Elo P/N: E894921
5 year warranty coverage + AUR - Elo P/N: E895125
Regulatory approvals and declarations Australia RCM; Canada cUL, IC; China CCC; Europe CE TUV; Japan VCCI; Korea KCC; Mexico CoC; Taiwan BSMI; United States UL, FCC; International CB; RoHS, China RoHS, WEEE
Mounting Options 75 mm VESA mount
Flush mount with included brackets
2-hole mounting interface on all 4 sides
See dimensional drawings for details
What's in the Box HDMI Cable
VGA Cable
Remote OSD
Flush Mount Brackets w/Screws (TouchPro PCAP Models)
Touch USB Cable
Quick Install Guide
EEI Label
Japan Class-B TM info sheet
Options / Peripherals / Upgrades Elo Remote OSD (RJ45) - Elo P/N: E483757
Elo Backpack - Elo P/N: E611864
Elo Backpack 3.0 - Elo P/N: E901355
Replacement Cable Kit - Elo P/N: E546861
Cable Kit DVI-D to HDMI – Elo P/N: E538507
Cable Kit DP to DP – Elo P/N: E582895
North America power brick - Elo P/N: E005277
European & Korea power brick - Elo P/N: E571601
UK power brick - Elo P/N: E180092
China power brick - Elo P/N: E558862
Taiwan power brick - Elo P/N: E818655
Japan power brick - Elo P/N: E182546
Argentina power brick - Elo P/N: E887099
Australia power brick - Elo P/N: E637593
IntelliTouch Stylus Pen - Elo P/N: D82064-000
Elo 10-inch Flush-mount Bracket - Elo P/N: E511656
Power DC 24V/DC 12V Converter - Elo P/N: E239980
Optional PCAP Stylus Pen E066148



10.1" Elo E321195 1093L LCD (LED Backlight), Open Frame, HDMI, VGA & Display Port video interface, Projected Capacitive 10 Touch Zero-Bezel, USB touch controller interface, Worldwide-version, Clear, No power brick

The Elo 1093L 10-inch open frame touchscreen display delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. Designed with reliability from the start, Elo's open frames deliver outstanding image clarity and light transmission with stable, drift-free operation for accurate touch responses. The 90-Series product line is available in a wide range of sizes, touch technologies and brightness, offering the versatility needed for commercial kiosk applications from self-service and gaming to industrial automation and healthcare.

Condition: Brand new with original manufacturer warranty.
Most items in stock – please call to verify if order is urgent.

When ordering this item, use this part number: E321195



Elo Part Number: ET1093L-2UWB-0-MT-ZB-NPB-G
